EMC troubleshooting, pre compliance, FCC, ETSI
We have +10y experience in RF measurements, pre-compliance, antenna anechoich chamber measurements, shielded boxes, passing ETSI, FCC and other regulations.
Quad Channel Coherent SDR
Quad channel USB connected, coherent Software Defined Radio. Designed from scratch till mass production.
RTL2832U based Software Defined Radio
Single channel USB connected Software Defined Radio with USB HUB feature. Designed from scratch till mass production.
Solar + battery micro grid solution
Complete redesign of a battery charger and power module PCB with solar panel input. The design has 300 components on a PCB with only 2 layers, handling 10+ Amps.
RF Generator /w Silabs EFM8 MCU
USB powered, standalone operation. Designed from scratch till mass production.
0603 inductor RFID antenna
probably worlds most miniature and cheapest RFID antenna
Raspberry Pi Standalone Speaker Amplifier HAT
Using Raspberries on board PWM audio generator feature adding our some filters and audio amplifier plus the speaker: creating a stand alone active speaker HAT for Raspberry Pi community.
NFC boot loader design
RF HW design considering antenna simulation and tuning, FW design for the boot loader features.
RF HW consulting
Transform of a low cost commercial product into high fidelity RF device via clever RF architecture redesign on board.
Standalone Frequency Mixer
Standalone USB powered frequency mixer and generator device.
QRPi the radio front end module for Raspberry Pi
A Band Pass Filter + amplifier stage for SDR transmission experiments.
Bluetooth, Zigbee, Wifi antenna simulation and design
From idea till mass production
proxmark3 cad / cam contribution
We helped to ease the manufacturability of the famous proxmark3 tool pcbs
Remote radio head on drone for spectrum monitoring
Our R&D task focused on creating an “improvised relay” for radio communication use cases or 3D radio spectrum mapping
CNC Black Box – SD card to RS232 adapter
CNC Black Box – a Battery Powered CNC RS232 SDCard Data Uploader! CNC Black Box which will be an economical solution to keep your CNC-s updated and running non-stop.
ISM SoC Radios, RFID, Antenna design, EMC trobuleshooting
System Level Design, 8bit MCU, EFM32, ARM, FPGA, Sensors
Creating custom Android and iOS app for our HW
Cost effective Software Defined Receiver and Transmitter solutions
European and US mid size to global multinational companies. Startups.
OUR Engineering Pool
Latest New - IoT Blog
SMOG-1 pocket satellite reception how to
You can find all the Windows, Linux, Raspberry Pi based receiver software package here:https://gnd.bme.hu:8080/ So far the “best guess” for the Kepler element data is here:https://www.celestrak.com/NORAD/elements/tle-new.txt hint: for smogcli program you need to add -i 47939 ID for reception. Stay tuned for updated TLE elements, hope NORAD can do the radar measurements and fine tune Read more about SMOG-1 pocket satellite reception how to[…]
SMOG-P ACCOMPLISHES ITS MISSION
“The Earth-orbiting mission of the BME developed picosatellite has ended: it entered the denser parts of the atmosphere on September 28 2020 and disintegrated. After spending the sensationally long time of nearly 10 months in space, the world’s first functional pocket-sized (5x5x5cm) satellite, 1-PocketQube burned up in the atmosphere. Despite a planned lifecycle of 3 Read more about SMOG-P ACCOMPLISHES ITS MISSION[…]
SMOG-P: A Successful Space Project
An article about the collected electrosmog data of SMOG-P satellite:http://gnd.bme.hu/smog/files/publikaciok/smogp_spectrum_measurement.pdf
officeAir – A temperature and Humidity Meter and Google Sheet Logger with Raspberry Pi and I2C sensors
This project lets you log temperature and humidity data via Raspberry Pi and a sensor easily and automated way into you google sheet, collecting the raw data and automatically drawing a nice chart as data coming in. (The name and use case comes from life: initially we set this up to monitor DecentLabs office climate Read more about officeAir – A temperature and Humidity Meter and Google Sheet Logger with Raspberry Pi and I2C sensors[…]
Starlink observation of the 22.04.2020 launched satellite fleet from Budapest, Hungary
Latest news about “dark satellite” development for reducing reflections, quite interesting engineering problems: https://www.spacex.com/news/2020/04/28/starlink-update
Understanding the rotation of SMOG-P pocket satellite from H/V polarized IQ samples
Courtesy of HA7WEN, Levente Dudás: http://bit.ly/smogp_rotation
RTL-SDR V3 based basic receiver station for SMOG-P and ATL-1 Nano Satellites
SMOG-P is currently the world’s smallest _operating_ satellite as far as I know. These wonderful tiny pocket satellites are designed in Hungary by the professors and students of Budapest University of Technology and Economics: “Apart from the units ensuring its basic operations, the payload of SMOG-P is a spectrum analyzer, measuring man-made electromagnetic pollution in Read more about RTL-SDR V3 based basic receiver station for SMOG-P and ATL-1 Nano Satellites[…]
Modifying EDUP EP-AB007 4W bi-directional Wifi amplifier for OA-100 Es’hail satellite operation, non-stop TX mode
4 and 8 Watt WiFi bi-directional amplifiers are designed for about 10-20 dBm input power. They listening in their input for a relatively strong signal to decide whether turn over to TX state from RX state (and changing over RF switches). Doing this simply rectifying the inrush RF power and leading that into an amplifier Read more about Modifying EDUP EP-AB007 4W bi-directional Wifi amplifier for OA-100 Es’hail satellite operation, non-stop TX mode[…]
Celebrating successful Es’hail 2 / QO-100 GEO HAM satellite WSPR transmission using only 4 milliwatts
Setup:– WSPR transmitter: QRP Labs U3S kit at 2m mode WSPR, using GPS calibration (later might trying OCXO option)– 2m BPF– Morfeus converter – a Minicircuits ZX60-43-S+ RF amplifier block (single stage) – 2.4 GHz BPF– 5 turn LHCP helical and 1m parabolic dish– Virtual Audio Cable SW tool for routing web sdr audio to Read more about Celebrating successful Es’hail 2 / QO-100 GEO HAM satellite WSPR transmission using only 4 milliwatts[…]
Es’hail 2 / Qatar-OSCAR 100 bare LNB vs Parabolic dish reception test
Have seen an example of “bare LNB” reception of QO-100 GEO ham satellite from Andreas Preuss, DL5APR. That was quite shocking… So tried to reproduce that experiment using my own receiver setup. Looks like its works fine for stronger signals! I can imagine adding some tricks to the LNB’s horn antenna to improve it’s gain Read more about Es’hail 2 / Qatar-OSCAR 100 bare LNB vs Parabolic dish reception test[…]
